Print Head

2~4 Ricoh G5i  print heads

Curing System

Four Water Cooling LED UV Curing Lamps

Ink

Gongzheng UV Ink: RGI-3

Color Configuration

1xW+2xKCMY; 1xW+2xKCMY+1xV; 4xKCMY

Ink Supply System

2L Bulk Ink Supply System with White Ink Recirculation System

Media Thickness

Up to 150mm

Media Type

Acrylic, Aluminum Sheet, Foam Board, PVC Board, Leather, Glass Bottle, Golf Ball, Wood, Ceramic Tile, Souvenir, Toys, etc.

Printing Size

Max. 1600×1200mm

Printing Speed

Printing mode         Feather          Resolution         1×W+2×KCMY+1×V         4×KCMY

Draft                         Weak           720x600dpi                  17.2㎡/h                   34㎡/h

Production               Normal         720x600dpi                  14㎡/h                      28㎡/h

High-Resolution       Normal        720x900dpi                   11.4㎡/h                   23㎡/h

Photo                       Normal        720x1200dpi                  8.6㎡/h                    17㎡/h

Data Interface

Gigabit Ethernet

Working Environment

Temp. 20℃~30℃, Humidity: 35%~65%

Software

FlexiPRINT Mini UV +GZ Control Console

Power Requirement

Single-Phase, AC220V±10%, 50/60Hz,10A

Power Consumption

Printer: 1100W; UV Controller: 800W; Vacuum Blower: 2200W

Packed / Installed Size

LxWxH(mm): 3600x2300x1775 / 3290x1940x1456

G.W. / N.W.

1460KGS / 1100KGS
