Print Head

3-8 Ricoh Gen6  print heads

Resolution

720×900~720×2400dpi

Curing System

Dual water cooling LED UV curing lamps

Ink

UV curable Ink

Color Configuration

1xKCMY+1xWW+1xVV      1xKCMY+2xWW+2xVV
2xKCMY+1xWW                 2xKCMY+2xWW
3xKCMY                              2xKCMY+1xWW+1xVV
4xKCMY                              3xKCMY+1xWW

Ink Supply  System

Gntek negative pressure system and white ink stirring & circulation system

Ink Tank

2500ml

Media Thickness

Up to 100mm

Media Type

Acrylic, Aluminum shee, Foam boar, PVC  board, leather, Glass , Wood, Ceramic Tile, etc.

Table Size

2650×1325mm

Printing Size

Max. 2500×1300mm

Printing Speed

Mode              Resolution              2×KCMY            3×KCMY             4×KCMY

Draft               720x900dpi             40.3㎡/h            54.5㎡/h              66.2㎡/h

Production      720x1200dpi           33㎡/h               44.8㎡/h              54.9㎡/h

High-res          720x900dpi            26.2㎡/h             35.3㎡/h              43.9㎡/h

Photo              720x1200dpi          20㎡/h                27.7㎡/h              34.6㎡/h

Data Interface

External: USB3.0；Internal: Fiber Optical

Working Environment

Temp.20℃~30℃, Humidity: 35%~65%

Software

FlexiPRINT  UV +GZ control console

Power

Single-phase, AC220V±10%, 50/60Hz, 13A(Printer & UV control)+21A(Vacuum System )

Packed / Installed Size

LxWxH(mm): 4700x2300x1750 / 4452x2040x1495

G.W. / N.W.

1606KGS / 1200KGS
