Print Head

3~8 Ricoh Gen 5 Print Heads / 3~8 Ricoh Gen 6 Print Heads

Resolution

600x600~600x1800 dpi

Curing System

Dual Water Cooling LED UV Curing Lamps

Ink

UV Curable Ink

Color Config.

1xKCMY; 1xWW+1xKCMY; 1xWW+1xKCMY+1xVV; 2xWW+1xKCMY+2xVV;
2xKCMY; 2xWW+2xKCMY; 3xKCMY; 2xWW+3xKCMY

Ink Supply System

Negative Pressure System (White Ink Stirring and Circulation System)

Ink Tank

2500ml

Media Thickness

Max. 50mm

Media Type

Flexible Media: Ceiling Film, Vinyl, Frontlit, Backlit, Banner, Fabric, Wall Paper, Leather, etc.

Rigid Media: PVC Board, Foam Board, Corrugated Paper, Aluminum Sheet, Wood, etc.

Printing Width

Max. 3200mm

Printing Speed

Mode                Resolution            1xKCMY      2xKCMY        3xKCMY   /  1xKCMY       2xKCMY       3xKCMY

Draft                 600X600dpi          34.6㎡/h      61.6㎡/h         82.2㎡/h       37.1㎡/h       66.2㎡/h        87.9㎡/h

Production       600X900dpi          23.3㎡/h      43.1㎡/h         58.7㎡/h       25㎡/h          46.2㎡/h         62.6㎡/h
High-res           600X1200dpi        10.9㎡/h      20.8㎡/h         29.3㎡/h       11.8㎡/h       22.4㎡/h         31.6㎡/h

Photo               600X1800dpi         7.4㎡/h       14.2㎡/h         20.1㎡/h        8㎡/h           15.4㎡/h         21.6㎡/h

Data Interface

External: USB3.0;  Internal: Fiber Optical

Working Environment

Temp. 20℃~30℃, Humidity: 35%~65%

Software

FlexiPRINT UV Version+GZ Control Console

Power

Single-phase, 50/60Hz, AC220V±10%, 30A (Printer+Vacuum);  5A (UV Controller)

Installed / Packed Size

LxWxH(mm): 6450x2000x1659 / 6420x2100x1950 (Printer):

650x340x340 / 1230x810x720 (Blower & Chiller);  2682x1200x1093 / 3100x750x1630 (Extension Table)

N.W. / G.W.

2474KGS / 3200KGS (Printer); 108KGS / 144KGS (Blower & Chiller): 152KGS / 288KGS (Extension Table)
