RTR UV Solutions
GZM32KM PRO

Affordable 3.2m RTR UV Printer with Varnish Option


Konica 1024i/1024a High-Speed Print Heads

Negative Pressure System

LED UV Lamp & Anti-Collision Unit

Triple Pinch Rolls Take-up

Durable 400W AC Servo System

Water Cooling Platen

Model

GZM32KM PRO

Print Head

4~11 KM 1024a/1024i Heads

Head Config.

2xKCMY; 2xW+2xKCMY
1xW+2xKCMY+1xV; 2xW+2xKCMY+1xV

Curing System

LED UV Curing System

Ink

UV Curable Ink

Colors

KCMY+W+V

Ink Supply System

Negative Pressure System + White Ink Recirculation System

Servo System

Durable 400W AC Servo System

Media Handling System

Pinch Roller System with Multi-fuction Feeder+ Triple Pinch Rolls Take-up

Media Type

Backlit, Banner, Canvas, Backlit Film, Reflective Film, Tarpaulin, Backlit Textile, Vinyl, Wall Coverings, PP, PET...

Printing Width

Max. 3200mm

Printing Speed

Konica 1024a         Resolution         1 group head         2 groups heads

Draft                      480X1080dpi           32㎡/h                     63㎡/h
Production            480X1440dpi            27㎡/h                     51㎡/h
Quality                  480X1080dpi            19㎡/h                     38㎡/h
Hi-Precision          480X1440dpi            14㎡/h                     28㎡/h

Konica 1024i         Resolution         1 group head         2 groups heads

Draft                      540X1080dpi           36.5㎡/h                 67.5㎡/h
Production             540X1440dpi           28.6㎡/h                 53.5㎡/h
Quality                   540X1080dpi           19.4㎡/h                 37㎡/h
Hi-Precision           540X1440dpi           14.4㎡/h                 28.5㎡/h

Data Interface

External: USB2.0; Internal: SCSI cable

Working Environment

Temp. 20℃~28℃, Humidity: 40%~70%

Software

FlexiPRINT UV Edition (Optional Onyx)+ GZ Printer Manager

Power

Printer: Single-phase, 50/60Hz, AC220V±10%, 10A; Regulator: 10kVA

Installed / Packed Size

5200x1372x1606mm / 5340x1330x1840mm(Printer); 680x290x480mm / 750x450x670mm(UV Controller)

N.W / G.W.

1466KGS / 1699KGS(Printer); 19KGS / 38KGS(UV Controller)
