Print Head

5 x Epson I3200-A1 Print Heads

Printing Speed

Mode             Resolution                Output

6 Pass          720x1800dpi              28 sqm/h

Ink

GS Original Transfer Pigment Ink

Color Configuration

3xKCMY+2xW

Ink Supply System

1.5-Liter Bulk Ink Supply System with White Ink Recirculation System

Ink Tank

1500mm

Media Type

Transfer Film

Printing Width

600mm

RIP Software

Onyx DTF + GZ Printer Manager

Data Interface

External: Ethernet; Internal: Fiber Optical

Power

Single Phase, 50Hz/AC, 220V±10%, 4A

Working Environment

Temp: 18℃-30℃; Humidity: 35%-65%

Installed Size

LxWxH(mm): 1995x950x1610

Printer Packed Size

LxWxH(mm): 2160x1120x750

G.W. / N.W.

340KGS / 258KGS

SHAKER

Model

Pixy SK5

Heating & Drying System

Two Rows High-Efficient Drying Lamp & Cold Air Fan Drying

Power

Single Phase, 50Hz/AC, 220V±10%, 16A

Installed Size

LxWxH(mm): 2700x963x1043

Packed Size

LxWxH(mm): 2700x1150x1500

G.W. / N.W.

432KGS / 320KGS
