Print Head

16 x Epson I3200-A1 Print Heads

Ink

GS High Density Sublimation Transfer ink Certified by OEKO TEX with "ECO PASSPORT"

Color Config.

Y.M.K.C.

Ink Supply System

15-Liter Large Capacity Ink Tanks

Printing Width

Up to 1950mm

Media Type

Transfer Paper (31 to 100gsm)

Feeder

Feeding: 13000m or 3000m; Taking up: 3000m or 1500m

Roll Diameter

Feeding: up to 1000mm; Taking-up: up to 400mm

Drying System

3x IR Dryers

Printing Speed

Mode                 Resolution           Output

Draft                  720x600dpi          663㎡/h

Production        720x600 dpi          520㎡/h

High-Res           720x1200 dpi       359㎡/h

Photo                 720x1200 dpi       265㎡/h

Data Interface

External: USB3.0; Internal: Fiber Optical

Working Environment

Temp. 18℃~30℃, Humidity: 35%~65%

Software

neoStampa Delta / Ergosoft... + GZ Printer Manager

Power

Single Phase,50Hz/AC, 220V±10%, 25A (Printer) +3x27A (IR Dryer)

Packed Size(LxWxH)

4340x1150x2040 (Printer); 2790x1400x1340 (Myriameter Feeder); 2680x970x1280 (Kilometer Feeder)

Installed Size(LxWxH)

4071x912x1720 (Printer); 2592x1481x1078 (Myriameter Feeder); 2439x961x947 (Kilometer Feeder)

N.W. / G.W.

1652KGS / 1328KGS (Printer); 856KGS / 628KGS (Myriameter Feeder); 504KGS / 336KGS (Kilometer Feeder)
