Print Head

8 x Epson I3200-A1 Print Heads

Ink

GS High Density Sublimation Transfer ink Certified by OEKO TEX with "ECO PASSPORT"

Color Config.

K.C.Y.M; Optional 8 Colors: K.C.Y.M + S1.S2.S3.S4.

Ink Supply System

5-Liter Bulk Ink Supply System with Ink Cartridges

Printing Speed

Draft                       320x1200 dpi                  403㎡/h

Production              360x1200 dpi                  320㎡/h

High-Res                720x1200 dpi                  210㎡/h

Photo                      720x1200 dpi                 165㎡/h

Printing Width

Up to 3200mm

Media Type

Transfer Paper(45 to 85gsm)

Feeder

Feeding: 1000m; Taking up: 500m

Roll Diameter

Up to 350mm

Drying System

Intelligent Sectionable Control IR Dryer

Data Interface

External: USB3.0; Internal: Fiber Optical

Working Environment

Temp. 23℃~29℃, Humidity: 50%~80%

Software

neoStampa Delta / Ergosoft... + GZ Printer Manager

Power

Single Phase, 50Hz/AC, 220V±10%, 13A(Printer)+2x27A(IR Dryer)

Packed/Installed Size

LxWxH(mm): 5130x1300x1930 / 4956x1466x1850

G.W./ N.W.

1734KGS/ 1294KGS
