Print Head

4 x Epson I3200-A1 Print Heads

Printing Speed

Mode             Resolution                Output

4 Pass          720×1200 dpi             30㎡/h

6 Pass          720×1800 dpi             20㎡/h

Ink

GS Original Transfer Pigment Ink

Color Configuration

2xKCMY+2xW; KCMY+FoFgFyFm+2xW

Ink Supply System

1.5-Liter Bulk Ink Supply System with White Ink Recirculation System

Ink Tank

1500ml

Media Type

Transfer Film

Printing Width

600mm

RIP Software

Onyx DTF + GZ Printer Manager

Data Interface

External: Ethernet; Internal: Fiber Optical

Power

Single Phase, 50Hz/AC, 220V±10%, 16A

Working Environment

Temp: 18℃-30℃; Humidity: 35%-65%

Installed Size

LxWxH(mm): 1749x815x1539

Printer Packed Size

LxWxH(mm): 2260x1000x750

G.W. / N.W.

290KGS / 216KGS

SHAKER

Model

Pixy SK4

Heating & Drying System

Two Rows High-Efficient Drying Lamp & Cold Air Fan Drying

Power

Single Phase, 50Hz/AC, 220V±10%, 16A

Installed Size

LxWxH(mm): 2400x980x1050

Packed Size

LxWxH(mm): 2100x970x1040

G.W. / N.W.
