Print Head

5~8 Ricoh Gen6 print heads

Resolution

726×900-726×2400dpi

Curing System

Water cooling LED UV curing lamps

Ink

UV curable ink

Color Config.

2×KCMY+1×WW

2×KCMY+2×WW

3×KCMY+1×WW

3×KCMY+2×WW

4×KCMY

Ink Supply System

Gntek negative pressure system and white ink stirring & circulation system

Printing Speed

Mode                    Resolution         Feather         3×KCMY            4×CMYK

Draft                   720×900dpi        Gradient        69sqm/h             84sqm/h

Production         720×1200dpi      Gradient        54sqm/h             67sqm/h

Hi-resolution      720×900dpi        Uniform         39sqm/h             49sqm/h

Photo                 720×1200dpi      Uniform         31sqm/h             39sqm/h

Printing Size

Max. 3200×2000mm

Media Type

Acrylic, Aluminum sheet, Foam board, PVC board, Leather, Glass, Wood, Ceramic tile, etc.

Data Interface

External: USB3.0; Internal: Fiber Optical

Working Environment

Temp. 20℃~30℃, Humidity: 35%~65%

Software

PhotoPRINT+GZ Printer Manager

Power

Single-phase, 50/60Hz, AC220V±10%

13A(Printer & UV controller)+21A (Vacuum system)

Packed / Installed Size

L×W×H(mm): 5650x3280x1750/ 5400x3030x1500

G.W. / N.W.

2750KGS/ 2200KGS
