Print Head

3 Epson I1600-U1 Print Heads

Curing System

3x Air Cooling LED UV Lamps

Ink

Gongzheng UV Ink: REI-3

Color Configuration

KCMY; W+KCMY; W+KCMY+V

Ink Supply System

1.2L Bulk Ink Supply with White Ink Recirculation System

Media Thickness

Up to 180mm

Media Type

Acrylic, Aluminum Sheet, Foam Board, PVC Board, Leather,Glass Bottle, Wood, Ceramic Tile, etc.

Printing Size

Max.600x900mm

Printing Speed

Printing mode        Feather          Resolution             CMYK+W+V

Draft                        Weak           720x900dpi            4.2mins/sheet

Production             Normal          720x900dpi            5.1mins/sheet

Hi-resolution          Normal         720x1200dpi           6.7mins/sheet

Photo                      Strong         720x1200dpi           8.3mins/sheet

Data lnterface

Gigabit Ethernet

Working Environment

Temp. 20℃~30℃, Humidity: 35%~65%

Software

FlexiPRINT Mini UV+GZ Control Console

Power Requirements

Single-phase, AC220V±10%, 50/60Hz, 10A

Power Consumption

1050W

Installed / Packed Dimension

LxWxH(mm): 1528x1634x1368 (Frame Included) / 2250x1690x1130

G.W. / N.W.

544KGS / 374KGS
